24x48 (Layout 1) Tile Pattern Calculator
This layout sets 24x48 tile alone, three tiles to a repeating 72x80 module. Working with a more common tile size? 24x24 Tile Pattern covers the closest standard format.
One-Tile Pattern — 24x48 (Layout 1)
Opuslay — tile layout worksheet- Room:
- 3 m × 2.5 m
- Units:
- Metric (cm / m²)
- Anchor:
- Left · Top
- Layout angle:
- Straight
- Tile colours:
- Single colour
Material breakdown
| Format | Qty / Pattern | Share | Qty / Room | Area / Room |
|---|---|---|---|---|
| 60x120 cm | 3 | 100.0% | 15 | 7.50 m² |
| Total | 3 | 100% | 15 | 7.50 m² |
What you'll need to buy
Tiles to buy
| 60x120 cm | 13 tiles | 9.36 m² |
Total 13 tiles · 9.36 m² (incl. 25% cuts & breakage)
- Thin-set adhesive: ≈ 3 bags (22.7 kg) — recommended trowel: 12mm notch, large format
- Grout — the tile sets the joint width, not you:
- ≈ 1 bag (11.3 kg) — 3mm joint, rectified / tight-set tile
- ≈ 1 bag (11.3 kg) — 5mm joint, natural or non-rectified tile
It's the tile that decides the joint, not the setter — dry-lay a section to find your width. Assumes 9.5mm tile depth; adjust for your product.
Share & export
Save the One-Tile Pattern — 24x48 (Layout 1) layout to your moodboard, or send the link to your tiler — it reopens with your room dimensions.
